The Wharfedale DP-4035 is a lightweight, high-efficiency Class D power amplifier designed for professional audio applications. It delivers substantial power output across four channels and is stable down to 2Ω, making it suitable for demanding environments. The amplifier features a compact 1U rackmount design, comprehensive protection circuitry, and variable speed cooling fans for reliable performance.
Wharfedale DP-4035 Power Amplifier
40,650 EGP
✔️ 4-channel Class D amplifier
✔️ Stable down to 2Ω
✔️ Up to 2023W bridged power
✔️ Compact 1U rackmount design
- Top Brands
- Secure Payments
- Cash On Delivery Available
- 4-channel Class D amplifier
- Stable operation down to 2Ω
- Selectable gain settings: 1Vrms / 32dB / 26dB
- Balanced XLR inputs
- SpeakON-compatible output connectors
- Comprehensive protection: thermal, over-current, DC, short circuit
- Variable speed cooling fan
- Front panel: AC switch, 4 x channel gain knobs
- Rear panel: mode and limiter switches
- Indicators: power, protect, signal, limiter
Power Output:
Stereo Mode:
8Ω: 4 x 350W
4Ω: 4 x 595W
2Ω: 4 x 1012W
Bridged Mono Mode:
16Ω: 2 x 700W
8Ω: 2 x 1190W
4Ω: 2 x 2023W
Performance:
Frequency Response: 20 Hz – 20 kHz (±1 dB @ 8Ω)
THD+N: <0.05% (1W)
S/N Ratio: >105 dB
Damping Factor: >500
Slew Rate: >50 V/μs
Crosstalk: <-70 dB
Input:
Sensitivity: Selectable: 1Vrms / 32dB / 26dB
Impedance: 20 kΩ (balanced)
Max Input Level: 22 dBu (9.7 Vrms)
Controls & Indicators:
Front Panel: AC switch, 4 x channel gain knobs
Rear Panel: mode switch (parallel/stereo/bridge), limiter switch
Indicators: power, protect, signal, limiter
Cooling & Protection:
Cooling: variable speed fan
Protection: thermal, over-current, output DC, output short
Power Supply:
Voltage Range: 90 – 260 VAC, 50 – 60 Hz
| Weight | 8 kg |
|---|---|
| Dimensions | 37.6 × 48.5 × 4.4 cm |
