Midas DM12 – 12-Input Analog Live and Studio Mixer

18,600 EGP

✔️ 8 Midas microphone preamps with +48V phantom power
✔️ 2 stereo line input channels
✔️ 3-band EQ with sweepable mid-frequency on mono channels
✔️ 2 auxiliary sends with pre/post fader switching
✔️ Compact and durable design

WhatsApp Icon Check Availability
SKU: DM12 Categories: , , Tags: , , , , Brand:
  • Top Brands
  • Secure Payments
  • Cash On Delivery Available

The Midas DM12 is a versatile analog mixer designed for both live performances and studio recordings. It features 8 mono input channels equipped with Midas microphone preamplifiers, renowned for their low noise and high headroom, ensuring superior audio quality. Each mono channel offers a 3-band EQ with a sweepable mid-frequency, allowing precise tonal adjustments. Additionally, the DM12 includes 2 stereo line input channels, making it suitable for a variety of audio sources.

With 2 auxiliary sends per channel, users can create custom monitor mixes or integrate external effects processors. The compact form factor and robust construction make the DM12 an ideal choice for small venues, project studios, and portable applications.

    • 8 Midas microphone preamps with +48V phantom power
    • 2 stereo line input channels for versatile connectivity
    • 3-band EQ with sweepable mid-frequency on mono channels
    • 2 auxiliary sends with pre/post fader switching
    • 60mm long-life faders for precise level control
    • Balanced XLR main outputs for professional connectivity
    • 2-track RCA input/output for recording and playback
    • Rugged chassis construction for durability in portable applications
    • Auto-ranging universal switch-mode power supply

    Audio Inputs

    • Mono Inputs:

      • Type: 8 x XLR (balanced)

      • Gain Range: +10 dB to +60 dB

      • Maximum Input Level: +11 dBu @ +10 dB gain

      • Frequency Response: 20 Hz to 20 kHz (-1 dB)

      • Equivalent Input Noise (EIN): -131 dBu (20 Hz to 20 kHz, unweighted)

    • Line Inputs:

      • Type: 8 x 1/4″ TRS (balanced)

      • Gain Range: -10 dB to +40 dB

    • Stereo Inputs:

      • Type: 2 x 1/4″ TRS (balanced)

    Audio Outputs

    • Main Outputs:

      • Type: 2 x XLR (electronically balanced)

      • Maximum Output Level: +21 dBu

    • Monitor Outputs:

      • Type: 2 x 1/4″ TRS (balanced)

    • Auxiliary Outputs:

      • Type: 2 x 1/4″ TRS (balanced)

    • 2-Track Output:

      • Type: 2 x RCA (unbalanced)

    Equalization

    • Mono Channels:

      • High: 12 kHz, ±15 dB, shelving

      • Mid: 150 Hz to 3.5 kHz, ±15 dB, semi-parametric

      • Low: 80 Hz, ±15 dB, shelving

    • Stereo Channels:

      • High: 12 kHz, ±15 dB, shelving

      • Low: 80 Hz, ±15 dB, shelving

    Controls and Indicators

    • Faders:

      • 12 x 60mm precision long-life faders

    • Phantom Power:

      • Global +48V switch with LED indicator

    • Meters:

      • 2 x 4-segment LED ladders for main mix or soloed channels

    • PFL Indicator:

      • LED indicates when Pre-Fader Listen is engaged

    Power

    • Power Supply: Auto-ranging universal switch-mode

    • Voltage Range: 100V to 240V AC, 50/60 Hz

    • Power Consumption: 40W

    Weight3.9 kg
    Dimensions37 × 32.8 × 9.5 cm
