The Wharfedale TITAN-AX15 is a powerful 15″ active loudspeaker engineered for demanding audio applications. With a bi-amplified Class D design, it delivers 420W RMS and 840W peak power, ensuring clear and dynamic sound reproduction. The speaker features a new 3″ voice coil LF driver and a 1.75″ HF compression driver with a titanium diaphragm, providing enhanced durability and performance. Its 100° x 80° Hybrid Symmetry Horn ensures wide and consistent coverage. The integrated DSP offers six user-selectable presets, including FLAT, MONITOR, SPEECH, BASS, PUNCH, and LIVE, allowing for tailored sound profiles. Additional features include LED horn lighting, a 90Hz high-pass filter, and multiple mounting options, making it suitable for various live sound and installation scenarios.
Wharfedale TITAN-AX15 – 15″ Active Speaker
26,850 EGP
✔️ 15″ active bi-amplified loudspeaker with 420W RMS and 840W peak power
✔️ High SPL of 129 dB, ideal for medium to large venues
✔️ Advanced DSP with six user-selectable presets
✔️ Built-in LED horn lighting and robust construction
- Top Brands
- Secure Payments
- Cash On Delivery Available
- 420W RMS / 840W Peak power output
- 15″ LF driver with 3″ voice coil
- 1.75″ HF compression driver with titanium diaphragm
- 100° x 80° Hybrid Symmetry Horn coverage
- Six DSP presets: FLAT, MONITOR, SPEECH, BASS, PUNCH, LIVE
- LED horn lighting with on/off switch
- 90Hz high-pass filter
- Multiple mounting options: 35mm pole mount, 10 x M8 rigging points, optional wall-mount bracket
- Injection-molded polypropylene enclosure with rubber-padded handles
Acoustics:
Frequency Response (±3 dB): 50Hz – 20kHz
Frequency Range (-10 dB): 40Hz – 20kHz
Maximum SPL @ 1m: 129 dB
Nominal Coverage (H x V): 100° x 80°
Drivers:
Low Frequency: 15″ (381mm) with 3″ (75mm) voice coil
High Frequency: 1.75″ (44mm) compression driver, 1″ (25mm) exit, titanium diaphragm
Amplification:
Low Frequency Amplifier: 350W RMS / 700W Peak (Class D)
High Frequency Amplifier: 70W RMS / 140W Peak (Class D)
DSP & Controls:
Six DSP presets: FLAT, MONITOR, SPEECH, BASS, PUNCH, LIVE
High-pass filter: 90Hz
LED indicators: Power (green), Limiter (red)
Connectivity:
Input: Switchable balanced mic/line level (Channel 1)
Connectors: 2 x XLR & 2 x 1/4″ jack (Channel 1 Line/MIC)
Line Output: Switchable LOOP/MIX Balanced Female XLR
Power:
Power Supply: SMPS
AC Power Options: AC100-120V/220-240V~ 50/60Hz
Power on indicator: Rear LED
Enclosure & Mounting:
Material: Injection-molded polypropylene
Grille: 1.2mm steel
Mounting Options: 35mm receptacle with lock screw, 10 x M8 threaded inserts, optional wall-mount bracket
LED Horn Lighting: Yes, with on/off switch
| Weight | 27.7 kg |
|---|---|
| Dimensions | 39.5 × 48 × 72.8 cm |
