Electro‑Voice EKX-15 – 15″ Passive Loudspeaker

43,500 EGP

Add to Wishlist
Add to Wishlist
SKU: EKX-15 Categories: , , Tags: , , , Brand:
  • Top Brands
  • Secure Payments
  • Cash On Delivery Available
  • EKX-15: 1600 W (peak), 132 dB peak SPL utilizing high-sensitivity transducers designed and engineered by EV.
  • EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage.
  • Lightweight, compact 15-mm wood enclosure with internal bracing, and durable EVCoat finish.
  • Eight M10 threaded mounting points, aluminum pole mounts, and all-metal handles.
  • 90˚ x 60˚ pattern for best coverage on mid-size stages. 40˚ monitor angle with rubber feet.

    General Specifications:

    • Speaker Type: Full-range, two-way passive loudspeaker

    • Woofer Size: 15 inches

    • HF Transducer: DH-1M 1-inch titanium compression driver

    • LF Transducer: EVS-15M 381 mm (15 in)

    • Frequency Response (-3 dB): 75 Hz – 18 kHz (Full Space Measurement)

    • Frequency Range (-10 dB): 50 Hz – 20 kHz (Full Space Measurement)

    • Coverage (Nominal -6 dB) Horizontal: 90°

    • Coverage (Nominal -6 dB) Vertical: 60°

    • Crossover Frequency: 1.6 kHz

    • Power Handling (Continuous/Peak): 400 W / 1600 W

    • Nominal Impedance: 8Ω

    • Minimum Impedance: 7.2Ω

    • Axial Sensitivity (SPL, 1 W @ 1 m): 96 dB (Full Space Measurement)

    • Max. SPL/1m (calculated): 132 dB

    • Recommended High-Pass Frequency: 50 Hz

    Physical Characteristics:

    • Enclosure Material: 15 mm plywood with EVCoat finish

    • Grille: 18 AWG steel with powder coat

    • Suspension: Eight M10 threaded mounting points

    • Connector Type: Dual NL4

    Weight23.2 kg
    Dimensions42.9 × 43.2 × 68.5 cm
